GHC
Main features
• Floor plinth for air diffuser HC
• Standard height 50 mm
• Can be supplied in alternative heights
Description
• Floor skirting board (plinth) for displacement diffuser, with a standard height of 50 mm. Can be delivered in alternative heights; other heights must be specified in plain text when ordering.
Product sizes – HC (mm):
Ø100
Ø125
Ø160
Ø200
Ø250
Ø315
Color options
• Standard colour is white RAL 9003
• The product can be delivered in alternative colors as special order.
• GHC, IHC: Powder-coated steel sheet in white RAL standard color.
• The product should be installed on the floor against a wall and secured to the wall.
• The skirting board is screwed into the diffuser.
• The product's duct inlet spigot is connected to a circular duct.
• Any cladding/enclosure is installed using the frame parts supplied. The enclosure is screwed to the lower frame part, which is attached inside the front face of the diffuser. The upper frame part is attached to the wall or ceiling.
